SEALMASTER PN-206T 713826 Ball Insert Bearing, Cylindrical Bore, 30 mm Inside Dia., Standard Duty
Item: BE4VKZ
Model: PN-206T
In Stock
Get it by Wednesday, Apr 15
£222.56/unit
(Inc. VAT)
Trade Prices Available
Request Quote
Payment
Delivery
Specifications
| Bearing Insert Finish | Phosphorus Nickel Coated |
|---|---|
| Bore Dia. | 30 mm |
| Bore Shape | Straight |
| Cage Material | Polyphenylene Sulfide |
| Duty/series | Standard Series |
| Dynamic Radial Load Capacity | 4381 lbs. |
| End Cap | No |
| Fixed Vs. Expansion | No |
| Housing Type | Insert Only |
| Htc | 8482.10.5052 |
| Inner Race Heat Treat Method | Zone Hardened |
| Inner Race Length | 39.7 mm |
| Inner Race Profile | Wide Inner Ring |
| Insert Material | Steel |
| Insert Material Finish | Phosphorus Nickel Coated |
| Insert Material Grade | 52100 |
| Internal Clearance | Standard |
| Ip Rating | IP69K |
| Locking Type | Concentric |
| Lubrication Type | Calcium Sulfonate Nlgi 2 Nsf H1 Food Grade Grease |
| Max. Operating Temperature | 220°F |
|---|---|
| Max. Speed | 2300 RPM |
| Measure Units | Metric |
| Misalignment Capability | -2° to +2° |
| Misalignment Type | Static Only |
| Outer Race Od | 62 mm |
| Outer Race Profile | Spherical |
| Outer Race Width | 7/8" |
| Outer Ring Land Profile | Standard |
| Platform | PN Gold |
| Precision Rating | Abec 1 |
| Radial Static Load Capacity | 2567 lbs. |
| Radius | 1.02" |
| Replaceable Insert | No |
| Retainer Type | Land Riding Retainer |
| Rolling Element | Ball Bearing |
| Series | PN-T Series |
| Torx Cap Screw Length | 5/8" |
| Torx Cap Screw Size | #8-32 |
| Type Of Seal | Triple Lip Contact Seal |
Product Details
Yes
Shipping Information
| height | 3.96 |
|---|---|
| length | 6.98 |
| width | 6.98 |
| country of origin | MX |
|---|---|
| weight | 0.634500 |
