WEG PESW-B18V24AX-R66 13339406 Enclosed Starter, 3 Phase, 18A Rated, 11-17 A Range, On/Off Control, Plastic Crate, 180-208V50HZ/208-240V60HZ
Item: BD3AKP
Model: PESW-B18V24AX-R66
In Stock
Get it by Wednesday, Apr 15
£9.99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates
We deliver to your doorstep under DAP terms. Customs clearance is for your account
3/5/10/15 hp
Trade Prices Available
Request Quote
Payment
Delivery
Specifications
| Amps | 18A |
|---|---|
| Assembly Method | Plastic Crate |
| Assembly Method (start Key) | Plastic Crate |
| Auxiliary Contacts | NO/NC |
| Coil Frequency | 50/60 Hz |
| Coil Voltage | 180-208/208-240V AC |
| Connection Type | Screw Terminal |
| Control Voltage | 180-208/208-240V |
| Enclosure Type | NEMA 4/4X , NEMA 4X |
| Frequency | 60/50 Hz |
| Full Load Amperage Range | 11-17A |
| Horsepower Rating | 10 hp |
| Hp | 3 hp, 5 hp, 10 hp, 15 hp |
| Includes | Start, Stop and Reset Pushbuttons |
| Mounting | Wall |
| Number Of Poles | 3 |
| Overload Relay | 11-17A |
| Overload Type | Bi-Metallic |
| Phase | 3 |
| Phase Loss Sensitive | Yes |
| Power Poles | NO |
| Rated Current | 18A |
|---|---|
| Rated Operational Voltage | 600V |
| Sccr Rating | 5 kA |
| Series | PESW Series |
| Start Type | Direct Three Phase |
| Starter Type | Non Combination |
| Trip Class | Class 10 |
| Voltage | 200/230/460/575V AC |
| Voltage Rating | 600V AC |
| Button Color | Not Specified |
| Button Type | Unspecified |
| Control Devices | A On Off Button |
| Degree Of Protection | NEMA 4X |
| Maximum Power Rating | Not Applicable |
| Measuring Tool And Accessories | Not Applicable |
| no. of phases | 3 |
| over load | 11-17A |
| rated amps (ac-3) | 18A (CWB18) |
| Reference | PESW |
| Starters Complements | Does Not Contain |
Product Details
Magnetic Motor Starter
Shipping Information
| height | 15.24 |
|---|---|
| length | 29.46 |
| width | 16.51 |
| country of origin | BR |
|---|---|
| weight | 1.026000 |
