SEALMASTER SFMH-19 Flange-Mount Ball Bearing Unit, 1-3/16 Inch Bore
Item: BE4UVJ
Model: SFMH-19
In Stock
Get it by Thursday, Apr 16
£126.85/unit
(Inc. VAT)
Trade Prices Available
Request Quote
Payment
Delivery
Specifications
| Bearing Design | Non Expansion |
|---|---|
| Bearing Insert Coating | Black Oxide |
| Bearing Type | Ball Bearing |
| Bolt Center To Center Length | 3.25" |
| Bolt Size | 0.4375" |
| Bore Dia. | 1 3/16" |
| Bore Shape | Straight |
| Centerline To Front Face | 0.8675" |
| Duty Type | Standard Duty |
| End Type | Open End |
| Expansion | No |
| Family Series | Sealmaster Bearings, SFMH Series |
| Flange Type | 4 Bolt Flange |
| Foot Height | 0.531" |
| Housing Base | Solid |
| Housing Color | Gray |
| Housing Construction | One Piece |
| Housing Length | 4 1/4" |
| Housing Material | Cast Iron |
| Inner Race Heat Treat Method | Zone Hardened |
|---|---|
| Inner Race Length | 1.4975" |
| Insert Material | 52100 Bearing Steel, Black Oxided |
| Length Through Bore | 2.421875" |
| Locking Device | Setscrew Locking Collar |
| Locking Type | Set Screws |
| Misalignment Type | Static Only |
| Mounted Unit Duty | Material Handling Duty |
| Operating Temp. Range | -20°F to +220°F |
| Overall Height To End Cap | 2.41" |
| Overall Length Diameter | 4.25" |
| Pilot Configuration | No Pilot |
| Retainer Type | Land Riding |
| Seal Type | Single Lip Contact |
| Series | SFMH Series |
| Shaft Dia. | 1.1875" |
| Static Radial Load Capacity | 2567 lbf. |
| Type Of Bearing | Ball |
Product Details
+/-2°
Shipping Information
| height | 3.96 |
|---|
| weight | 1.215000 |
|---|
