| Angular Misalignment | 0.5° |
| Axial Motion | 0.006 in (0.15 mm) |
| B1 Max Shaft Penetration | 0.590 in |
| Balanced Design | Yes |
| Bore (B1) | 0.3750 in |
| Bore Tolerance | +0.001 in / -0.000 in |
| Finish | Bright |
| Finish Specification | Bright, No Plating |
| Forged Clamp Screw | M3 |
| Full Bearing Support Required? | Yes |
| Hex Wrench Size | 2.5 mm |
| Hub Width (LH) | 0.590 in |
| Length (L) | 1.875 in (47.6 mm) |
| Material Specification | Type 303 Austenitic, Non-Magnetic Bar |
| Max Parallel Misalignment | 0.131 in (3.33 mm) |
| Maximum Speed | 4,500 RPM |
| Mechanical Fuse? | Yes |
| Moment of Inertia | 0.0522 lb-in |
| Number of Screws | 1 ea |
| Outer Diameter (OD) | 1.313 in (33.3 mm) |
| Parallel Misalignment | 0.008 in (0.20 mm) |
| Recommended Inserts | OD21/33-AT |
| Recommended Shaft Tolerance | +0.0000 in / -0.0005 in |
| Screw Finish | Bright |
| Screw Material | 18-8 300 Series Stainless Steel |
| Seating Torque | 1.1 Nm |
| Temperature | Acetal Disk -10°F to 150°F (-23°C to 65°) |
| Torque Specifications | Torque ratings vary with insert selection |
| Zero-Backlash? | Yes |
| Ship weight (kg) | 0.1 |
| Ship height (cm) | 3.34 |
| Ship length (cm) | 4.76 |
| Ship width (cm) | 3.34 |
| Country of Origin | US |
