| Angular Misalignment | 1.5° |
| Axial Motion | 0.028 in |
| B1 Max Shaft Penetration | 0.452 in |
| Balanced Design | Yes |
| Bore (b1) | 0.3750 in |
| Bore Tolerance | +0.002 in / +0.001 in |
| Finish | Clear Anodized |
| Finish Specification | Clear Anodized |
| Forged Clamp Screw | M3 |
| Full Bearing Support Required? | Yes |
| Hex Wrench Size | 2.5 mm |
| Hub Width (lh) | 0.276 in |
| Length (l) | 0.945 in (24.0 mm) |
| Material Specification | 6082 Aluminum Bar |
| Maximum Speed | 15,000 RPM |
| Number Of Screws | 1 ea |
| Outer Diameter (od) | 1.457 in (37.0 mm) |
| Parallel Misalignment | 0.039 in |
| Peak Torque | 3 Nm |
| Rated Torque | 2 Nm |
| Recommended Inserts | CPFRG23/37-AT |
| Screw Finish | Black Oxide |
| Screw Location (r) | 14 mm |
| Screw Material | Alloy Steel |
| Seating Torque | 1.3 Nm |
| Space Between Hubs (ls) | 0.393 in (10.0 mm) |
| Temperature | -22°F to 175°F (-30°C to 80°C) |
| Torsional Stiffness | 1.70 Nm/Deg |
| Zero-backlash? | Yes |
| Ship weight (kg) | 0.02 |
| Ship height (cm) | 3.7 |
| Ship length (cm) | 2.4 |
| Ship width (cm) | 3.7 |
| Country of Origin | DE |
