| 20 | $21.54 |
| 200 | Request Quote |
| Angular Misalignment | 1.5° |
| Axial Motion | 0.020 in |
| B1 Max Shaft Penetration | 0.383 in |
| Balanced Design | Yes |
| Bore (b1) | 0.3750 in |
| Bore Tolerance | +0.002 in / +0.001 in |
| Finish | Clear Anodized |
| Finish Specification | Clear Anodized |
| Forged Clamp Screw | M2.5 |
| Full Bearing Support Required? | Yes |
| Hex Wrench Size | 2.0 mm |
| Hub Width (lh) | 0.276 in |
| Length (l) | 0.807 in (20.5 mm) |
| Material Specification | 6082 Aluminum Bar |
| Maximum Speed | 22,000 RPM |
| Number Of Screws | 1 ea |
| Outer Diameter (od) | 0.984 in (25.0 mm) |
| Parallel Misalignment | 0.028 in |
| Peak Torque | 1 Nm |
| Rated Torque | 0.7 Nm |
| Recommended Inserts | CPFRG16/25-AT |
| Screw Finish | Black Oxide |
| Screw Location (r) | 8 mm |
| Screw Material | Alloy Steel |
| Seating Torque | 0.7 Nm |
| Space Between Hubs (ls) | 0.255 in (6.5 mm) |
| Temperature | -22°F to 175°F (-30°C to 80°C) |
| Torsional Stiffness | 0.65 Nm/Deg |
| Zero-backlash? | Yes |
| Ship weight (kg) | 0.01 |
| Ship height (cm) | 2.5 |
| Ship length (cm) | 2.05 |
| Ship width (cm) | 2.5 |
| Country of Origin | DE |
