| B1 Max Shaft Penetration | 1.000 in |
| B2 Max Shaft Penetration | 1.000 in |
| Bore (b1) | 0.6250 in |
| Bore Tolerance | +0.0020 in / +0.0005 in |
| Clearance Diameter (c) Max | 1.514 in |
| Finish Specification | Bright, No Plating |
| Forged Clamp Screw | #10-32 |
| Full Bearing Support Required? | No |
| Hex Wrench Size | 5/32 in |
| Length (l) | 2 in |
| Material Specification | 2024-T351 Aluminum Bar |
| Maximum Speed | 4,000 RPM |
| Moment Of Inertia | 0.0575 lb-in |
| Number Of Screws | 4 ea |
| Nypatch Anti-vibration Hardware? | Yes |
| Outer Diameter (od) | 1 5/16 in |
| Rated Torque | 1450 in-lb |
| Recommended Shaft Tolerance | +0.0000 in / -0.0005 in |
| Screw Finish | Black Oxide |
| Screw Location (r) | 0.484 in |
| Screw Material | Alloy Steel with |
| Seating Torque | 76 lb-in |
| Small Bore (b2) | 0.5000 in |
| Temperature | -40°F to 225°F (-40°C to 107°C) |
| Zero-backlash? | Yes |
| Ship weight (kg) | 0.1 |
| Ship height (cm) | 3.34 |
| Ship length (cm) | 5.08 |
| Ship width (cm) | 3.34 |
| Country of Origin | US |
