| Item | Reducer |
| Assembly | FMQ-LL |
| Center Distance | 2.06" |
| Frame | 56C |
| Gear Type | Worm |
| Gearbox Type | Worm |
| Housing Material | Cast Iron |
| Input Bore (c Face) | 5/8" |
| Input Bore Size | 5/8" |
| Input Dia. | 5/8" |
| Input Keyway Size | 3/16" x 1.38" |
| Input Keyway Size (c Face) | 3/16" x 3/32" |
| Input Quill Dia. | 5/8" |
| Input Rpm | 1750 RPM |
| Input Style | C Face Quill |
| Keyway Size | 3/16" x 3/32" |
| Material | Cast Iron |
| Max. Input Hp | 0.916 hp |
| No. Of Gear Reductions | 1 |
| Output Diameter | 1" |
| Output Hp | 0.674 hp |
| Output Key Size | 1/4" x 1.44" |
| Output Rpm | 43 RPM |
| Output Shaft | Shaft |
| Output Shaft Assembly Code | LL |
| Output Shaft Dia. | 1" |
| Output Shaft Orientation | LL |
| Output Shaft Type | Left Handed Shaft |
| Output Style | LL |
| Output Torque | 971 lbs.-in. |
| Overhung Load | 1315 lbs. |
| Product Line | GR Series - Ironman Worm Gear Reducers |
| Reducer | Worm - Right Angle |
| Reduction Type | Single |
| Series | GR Series |
| Series Style | GRG-FMQ-LL |
| Service Factor | 1 |
| Shaft Seal Material | Viton |
| Ships Factory Direct | No |
| Weight | 32 lbs. |
| Ship weight (kg) | 14.4 |
| Ship height (cm) | 26.67 |
| Ship length (cm) | 27.15 |
| Ship width (cm) | 23.01 |
| Model | Price | |
|---|---|---|
| GRG8215654.00 | £1,278.98 | |
| GRG8210125.00 | £895.25 | |
| GRG8210118.00 | £895.25 | |
| GRG8210113.00 | £895.25 | |
| GRG8210175.00 | £1,127.10 | |
| GRG8210117.00 | £895.25 | |
| GRG8210115.00 | £895.25 |
