ASHCROFT 25 1490A 02L 100 H20 Low Pressure Gauge, For Natural Gas & Other Gases, 0 to 100 Inch wc, 2 1/2 Inch Dial

Item: AB9CZB
Model: 25 1490A 02L 100 H20
25 In Stock

Ships within 2 days via

Pressure Range
£104.84
5.00% off
£99.6/unit (Inc. VAT)
Trade Prices Available
Request Quote

Payment

Specifications

Accuracy +/-2-1-2%
Accuracy Grade ASME B40.100 Grade A
Accuracy Scale Mid Scale
Adjustable Pointer No
Ambient Operating Temperature Range -4°F to +140°F
Application Air Compressors, Filtration Monitoring, Flow Measurement, Gas Measurement, Oem Applications, Regulators And Respirators, Vacuum Applications
Basic Gauge Case Material Plastic
Basic Gauge Sensor Material Copper
Basic Gauge Socket Material Brass
Bezel Material Polycarbonate
Bezel Mounting Type Bayonet
Bolt Circle Dia. 2.13"
Burst Pressure 5 psi
Calibration Certificate Included No
Case Color Black
Case Depth 1.65"
Case Dia. 2 7/8"
Case Diameter 2.875"
Case Material Polysulfone
Cleaned For Oxygen Service No
Color Black
Compatible Process Media Natural Gas
Connection Location Lower
Dial Color White
Dial Face Material Aluminum
Dial Size 2 1/2"
Dry Dampening Feature Not Available
Field Fillable No
Freeze Resistant Movement No
Gauge Accuracy Grade Grade A Industrial
Gauge Application For Natural Gas and Other Gases
Gauge Case Color Black
Gauge Case Liquid None
Gauge Case Material Polysulfone
Gauge Connection Location Bottom
Gauge Connection Size 1/4"
Gauge Nominal Dial Size 2 1/2"
Gauge Primary Range Units In Wc
Gauge Socket Material Brass
Gauge Type Low Pressure Diaphragm
Gauge Wetted Parts Brass, Beryllium Copper
Hazardous Location Rating Not Rated
Includes Mounting Hardware No
Includes Vent Plug No
Ip/nema Rating Nema Ip54
Lens Material Polycarbonate
Lens Material - Gauge Plastic
Liquid Filled No
Liquid-filled Case No
Mounting Hardware Included No
Mounting Type Flush Mount, U Clamp
Nominal Dial Size 2 1/2"
Operating Temp. Range -4°F to +140°F
Panel-mountable No
Pointer Color Black
Pointer Material Aluminum
Pressure And Vacuum Gauge Type Pressure Gauge
Pressure Gauge Type Low Pressure Gauge
Pressure Range 0 in. wc to 100 in. wc
Pressure Range Type Pressure
Primary Pressure Range 0 psi to 100 psi
Primary Scale Minor Graduations 1
Primary Scale Units In Wc
Process Connection 1/4" NPT Male
Process Connection Gender Male
Process Connection Location Bottom
Process Connection Size 1/4"
Process Connection Type NPT
Range 0 in. wc to 100 in. wc
Removable Bezel Yes
Scale Type Single
Sensor Material Beryllium Copper
Sensor Type Diaphragm
Series 1490 Series
Smallest Graduation 1 in. H2O
Socket Material Brass
Tube Material Beryllium Copper
Wetted Parts Material Brass, Beryllium Copper
Accuracy -1% to +1%
Ambient Operating Temp. Range -4°F to 140°F
Basic Gauge Lens Material Plastic
Basic Gauge Wetted Parts Brass, Copper
Calibration Certificate No
Case Dia. 2.875"
Case Liquid None
Case Material Glass Filled Polysulfone
Connection Size 1/4"
Connection Type MNPT
dia. 2 7/8"
Dial Material Aluminum
Graduations 1 in. wc
Ip Rating IP54
Material Glass Filled Polysulfone
Operating Temp. -4°F to +140°F
Panel Mountable No
Primary Range Smallest Graduation 1
Primary Range Units in. wc
Primary Range Values 0 to 100
Primary Scale Units in. wc
Smallest Graduation 1 in. wc
Type Pressure Gauge
Vibration Resistance None

Product Details

Shipping Information

Height 4.19
Length 7.3
Width 7.3
HS Code 9026208000
Country Of Origin US
Weight 0.157500
