WEG PESW-B12D15AX-R64 13438746 Enclosed Starter, 3 Phase, 12A Rated, 8-12.5 A Range, On/Off Control, Plastic Crate, 120V50/60HZ

Item: BD2WQN
Model: PESW-B12D15AX-R64
In Stock

Get it by Thursday, Apr 16

£246.66/unit (Inc. VAT)
Trade Prices Available
Request Quote

Payment

Delivery

Specifications

Amps 12A
Assembly Method Plastic Crate
Assembly Method (start Key) Plastic Crate
Auxiliary Contacts NO/NC
Coil Frequency 50/60 Hz
Coil Voltage 120V AC
Connection Type Screw Terminal
Control Voltage 120V
Enclosure Type NEMA 4/4X , NEMA 4X
Frequency 60/50 Hz
Full Load Amperage Range 8-12.5A
Hp 3 hp, 7 1/2 hp, 10 hp
Hp Rating 7 1/2 hp
Includes Start, Stop and Reset Pushbuttons
Mounting Wall
Number Of Poles 3
Overload Relay 8-12.5A
Overload Type Bi-Metallic
Phase 3
Phase Loss Sensitive Yes
Power Poles NO
Rated Current 12A
Rated Operational Voltage 600V
Sccr Rating 5 kA
Series PESW Series
Start Type Direct Three Phase
Starter Type Non Combination
Trip Class Class 10
Voltage 200/230/460/575V AC
Voltage Rating 600V AC
Button Color Not Specified
Button Type Unspecified
Control Devices A On Off Button
Degree Of Protection NEMA 4X
Maximum Power Rating Not Applicable
Measuring Tool And Accessories Not Applicable
no. of phases 3
over load 8-12.5A
rated amps (ac-3) 12A (CWB12)
Reference PESW
Starters Complements Does Not Contain

Product Details

Shipping Information

Height 15.24
Length 29.46
Width 16.51
Country Of Origin BR
Weight 1.021500
