WATTS 77F-DI-FDA-125 4 0825212 Y Strainer, 4 Inch Inlet, 178 Deg. C, 200 Psi Pressure
Item: CB3FJR
Model: 77F-DI-FDA-125 4
In Stock
£1015.92/unit
(Inc. VAT)
Trade Prices Available
Request Quote
Payment
Delivery
Specifications
| Item | Y Strainer |
|---|---|
| Blowdown Outlet Connection | Female Threaded |
| Blowdown Outlet Size | 1 1/2" |
| Body Material | Cast Iron |
| Body Style | Wye |
| Bolt Material | Steel |
| Buy American Act Compliant | No |
| Class Rating | 125 |
| Control Type | Not Applicable |
| Cover Material | Cast Iron |
| Cover Type | Tapped With Closure Plug |
| Epoxy Coating Type | Fda Approved |
| Flange Material | Cast Iron |
| Gasket Material | Graphite |
| Grooved Coupling Material | Not Applicable |
| Inlet Connection | Flanged Joint |
| Inlet Connection Size | 4" |
| Inlet Size | 4" |
| Inlet Thread Type | Not Applicable |
| Inlet Type | Flanged Joint |
| Lead | Not Present |
| Lead Free | Yes |
| Max. Operating Temp. | 353°F |
| Max. Pressure | 200 psi |
| Max. Temp. | 353°F |
|---|---|
| Maximum Pressure And Temperature | 200 psi @ 210°F, 125 psi @ 353°F |
| Maximum Working Pressure And Temperature | 200 psi At 210°F, 125 psi At 353°F |
| Mfr. Series | 77F-DI-FDA-125 |
| Min. Temp. | 32°F |
| Outlet Connection | Flanged Joint |
| Outlet Connection Size | 4" |
| Outlet Connection Thread Type | Flanged Joint |
| Outlet Size | 1 1/2" |
| Outlet Thread Type | Not Applicable |
| Outlet Type | Flanged Joint |
| Plug Material | Iron |
| Pressure Rating | 13.8 Bar, 8.6 Bar |
| Pressure-temperature Rating | 13.8 bar @ 99°C, 8.6 bar @ 178°C |
| Retainer Cover Material | Cast Iron |
| Retainer Cover Type | Tapped With Closure Plug |
| Screen Material | Stainless Steel |
| Screen Size | 1/8" |
| Seat Material | Not Applicable |
| Series | 77F-DI-FDA-125 Series |
| Strainer | Wye |
| Strainer Type | Wye |
| Wog (psi) | 200 psi |
Product Details
Related Products
| Style | Model | Blowdown Outlet Connection | Inlet Size | Outlet Size | Max. Operating Temp. | Pressure Rating | Strainer Type | Cover Type | Inlet Thread Type | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 77F-DI-FDA-125 10 | Flanged Joint | 250 mm | 10" | - | - | Wye | Tapped With Closure Plug | Not Applicable | 4,660.28 | |
| A | 77F-DI-FDA-125 12 | Flanged Joint | 12" | 2" | - | - | - | Tapped With Closure Plug | Not Applicable | 10,152.23 | |
| B | 77F-DI-FDA-125 6 | Flanged Joint | 150 mm | 6" | 178°C | 13.8 Bar | Wye | Tapped With Closure Plug | Not Applicable | 1,434.68 | |
| A | 77F-DI-FDA-125 8 | Flanged Joint | 8" | 2" | 353°F | 13.8 Bar, 8.6 Bar | Wye | Tapped With Closure Plug | Not Applicable | 2,505.56 | |
| A | 77F-DI-FDA-125 2 | Flanged Joint | - | - | - | - | Wye | - | Not Applicable | 637.19 | |
| A | 77F-DI-FDA-125 2 1/2 | Flanged Joint | - | - | - | - | Wye | - | Not Applicable | 372.79 | |
| C | 77F-DI-FDA-125 3 | Flanged Joint | - | - | - | - | Wye | - | Not Applicable | 470.25 |
