TRITAN SS61805 ZZ FM222 Radial Ball Bearing Stainless Steel 25mm Ss61805zz
Item: AG4ZHR
Model: SS61805 ZZ FM222
In Stock
Get it by ,
We deliver to your doorstep under DAP terms. Customs clearance is for your account
5.00% off
₹47.000000
(ex. VAT)
Trade Prices Available
Request Quote
Payment
Delivery
Specifications
| Abec Rating | 1 |
|---|---|
| Abec Tolerance | 1 |
| Ball Material | Stainless Steel |
| Bearing Industry Number | 61805, 6805 |
| Bearing Material | Stainless Steel |
| Bearing Type | Double Shielded Ball |
| Bore Dia. | 25 mm |
| Bore Diameter | 25 mm |
| Bore Diameter Tolerance | -0.01 mm to 0 mm |
| Bore Tolerance | -0.01 mm to 0 mm |
| Cage Material | Stainless Steel |
| Cage Material Grade | Grade 304 |
| Closure | Double Shielded |
| Contact Type | Radial |
| Dynamic Load Capacity | 1010 lbs. |
| Dynamic Radial Load Capacity | 967 lbf. |
| For Environment | Caustic, Chemical, Food And Beverage, Pharmaceutical, Poultry |
| Industry Number | SS61805ZZ |
| Lubricant Material | High Quality Food Grade Grease |
| Lubrication | Grease |
| Max. Speed | 22000 RPM |
|---|---|
| Maximum Axial Load | 1010 lbf. |
| Maximum Speed | 18000 RPM |
| Maximum Temperature | 350°F |
| Mfr Part | SS61805 ZZ FM222 TRITAN |
| Minimum Temperature | -40°F |
| Number Of Rows | 1 |
| Outer Ring Width | 7 mm |
| Outside Dia. | 37 mm |
| Outside Dia. Tolerance | -0.01 mm to +0.01 mm |
| Outside Diameter | 37 mm |
| Outside Diameter Tolerance | -0.01 mm to 0 mm |
| Resistance Properties | Corrosion Resistant |
| Ring Material | Stainless Steel |
| Shield Material | Stainless Steel |
| Static Load Capacity | 710 lbs. |
| Static Radial Load Capacity | 663 lbf. |
| Temp. Range | -40°F to +350°F |
| Width | 7 mm |
Product Details
Radial Ball Bearing
Shipping Information
| height | 0.7 |
|---|---|
| length | 3.7 |
| width | 3.7 |
| hs code | 8482105052 |
|---|---|
| weight | 0.022500 |
Related Products
| Style | Model | Industry Number | Closure | Outer Ring Width | Bore Dia. | Outside Dia. | Max. Speed | Bore Tolerance | Static Radial Load Capacity | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | SS61804 ZZ FM222 | SS61804ZZ | Double Shielded | 7 mm | 20 mm | 32 mm | 26000 RPM | -0.01 mm to 0 mm | 555 lbf. | 41.14 | |
| A | SS61806 ZZ FM222 | SS61806ZZ | Double Shielded | 7 mm | 30 mm | 42 mm | 18000 RPM | -0.01 mm to 0 mm | 821 lbf. | 72.80 | |
| A | SS61807 ZZ FM222 | SS61807ZZ | Double Shielded | 7 mm | 35 mm | 47 mm | 16000 RPM | -0.012 mm to 0 mm | 920 lbf. | 81.41 | |
| A | SS61808 ZZ FM222 | SS61808ZZ | Double Shielded | 7 mm | 40 mm | 52 mm | 14000 RPM | -0.012 mm to 0 mm | 980 lbf. | 119.97 | |
| A | SS61900 ZZ FM222 | SS61900ZZ | Double Shielded | 6 mm | 10 mm | 22 mm | 38000 RPM | -0.008 mm to 0 mm | 286 lbf. | 16.63 | |
| A | SS61901 ZZ FM222 | SS61901ZZ | Double Shielded | 6 mm | 12 mm | 24 mm | 36000 RPM | -0.008 mm to 0 mm | 328 lbf. | 20.07 | |
| A | SS61902 ZZ FM222 | SS61902ZZ | Double Shielded | 7 mm | 15 mm | 28 mm | 30000 RPM | -0.008 mm to 0 mm | 463 lbf. | 25.49 |
