| Ability To Relubricate | Yes |
| Base Length | 13 3/4" |
| Base To Center Height | 3 3/4" |
| Base Width | 3.38" |
| Bearing Insert Finish | Black Oxide |
| Bearing Insert Material | Steel |
| Bearing Insert Material Grade | 52100 |
| Bearing Insert Type | Medium Duty |
| Bolt Size | 7/8" |
| Bolt Spacing Max | 11 1/2" |
| Bolt Spacing Min | 10" |
| Bore Dia. | 2 15/16" |
| Bore Shape | Straight |
| Cage Material | Brass |
| Cage Type | Land Riding Retainer |
| Centerline To Outermost Bearing Face | 1.938" |
| Dynamic Load Capacity | 17412 lbs. |
| End Cap | No |
| Fixed Vs. Expansion | Fixed |
| Foot Height | 1.19" |
| Grease Fitting Thread Size | 1/4" |
| Grease Fitting Thread Type | NPT |
| Housing Base | Solid |
| Housing Coating | Powder Coated |
| Housing Color | Black |
| Housing Construction | One Piece |
| Housing Material | Cast Iron |
| Housing Style | Pillow Block |
| Housing Type | Pillow Block, Two Bolt |
| Htc | 8483.20.8040 |
| Inner Race Heat Treat Method | Zone Hardened |
| Inner Ring Outside Diameter | 3.922" |
| Insert | 3-215DC |
| Length Through Bore | 3 7/8" |
| Lubrication Type | Lithium Complex NLGI 2 Grease |
| Max. Operating Temperature | 220°F |
| Max. Speed | 1950 RPM |
| Misalignment Capability | -2° to +2° |
| Misalignment Type | Static Only |
| Outer Ring Land Profile | Standard |
| Overall Height | 7 1/2" |
| Overall Length | 13 3/4" |
| Overall Width | 3 22/25" |
| Radial Clearance | Standard |
| Rolling Element | Ball Bearing |
| Seal Type | Single Lip Contact Seal |
| Setscrew Torque | 500 lbs.-in. to 650 lbs.-in. |
| Shaft Locking Type | Double Set Screw |
| Size Code | 2-33 |
| Static Load Rating | 13174 lbs. |
| Vibration Frequency Fundamental Train | 0.0069 cPS |
| Vibration Frequency Inner Ring Defect | 0.1074 cPS |
| Vibration Frequency Outer Ring Defect | 0.0759 cPS |
| Vibration Frequency Roller Spin | 0.0470 cPS |
| Ship weight (kg) | 14.85 |
| Ship height (cm) | 20.47 |
| Ship length (cm) | 36.2 |
| Ship width (cm) | 10.16 |
| Country of Origin | US |
