| Back Side To Center Width | 2.328" |
| Bearing Insert Material | Alloy Steel |
| Bearing Insert Type | Radial Ball |
| Bore Diameter | 3 15/16" |
| Bore Type | Cylindrical |
| Closure | Double Sealed |
| Dynamic Load Capacity | 29905 lbf. |
| Expansion Type | Fixed |
| Flange Thickness | 1 1/4" |
| Housing Material | Cast Iron |
| Housing Material Finish | Powder Coated |
| Housing Type | Square |
| Included Bearing | UCX20-63 |
| Includes | Set Screw |
| Lubrication Openings | One Zirc Fitting |
| Maximum Speed | 1700 RPM |
| Mount Hole Center-to-center Height | 8 1/8" |
| Mount Hole Center-to-center Length | 8 1/8" |
| Mount Hole Size | 1.21875" |
| Mounting Bolt Size | 1" |
| Overall Height | 10 9/16" |
| Overall Length | 10 9/16" |
| Overall Width | 4 5/8" |
| Seal Material | Felt |
| Seal Type | Triple Lip |
| Self Lubricating Bearing | No |
| Shaft Locking Type | Set Screws |
| Static Radial Load Capacity | 23553 lbf. |
| Ship weight (kg) | 25.21 |
| Ship height (cm) | 27.94 |
| Ship length (cm) | 27.94 |
| Ship width (cm) | 16.84 |
| Country of Origin | US |
