| B1 Max Shaft Penetration | 0.984 in (25.0 mm) |
| B2 Max Shaft Penetration | 0.984 in (25.0 mm) |
| Balanced Design | Yes |
| Bore (b1) | 16 mm |
| Bore Tolerance | +0.0020 in / +0.0005 in (+0.050 mm / + 0.012 mm) |
| Clearance Diameter (c) Max | 1.551 in (39.4 mm) |
| Finish Specification | Bright, No Plating |
| Forged Clamp Screw | M5 |
| Full Bearing Support Required? | No |
| Hex Wrench Size | 4.0 mm |
| Keyway (k1) | 5 mm |
| Keyway (k2) | 1/8 in |
| Length (l) | 1.969 in (50.0 mm) |
| Material Specification | Type 303 Austenitic, Non-Magnetic Bar |
| Maximum Speed | 4,000 RPM |
| Moment Of Inertia | 0.152836 lb-in |
| Number Of Screws | 8 ea |
| Nypatch Anti-vibration Hardware? | Yes |
| Outer Diameter (od) | 1.339 in (34 mm) |
| Rated Torque | 531 in-lb (60 Nm) |
| Recommended Gap | 0.063 in (1.60 mm) |
| Recommended Shaft Tolerance | +0.0000 / -0.0005 " (+0.000 / -0.013 mm) |
| Screw Finish | Bright |
| Screw Location (r) | 0.472 in (12.0 mm) |
| Screw Material | 18-8 300 Series Stainless Steel with |
| Seating Torque | 5.4 Nm |
| Small Bore (b2) | 0.5000 in |
| Temperature | -40°F to 350°F (-40°C to 176°C) |
| Zero-backlash? | Yes |
| Ship weight (kg) | 0.27 |
| Ship height (cm) | 3.4 |
| Ship length (cm) | 5 |
| Ship width (cm) | 3.4 |
| Country of Origin | US |
