| Bore (b1) | 20 mm |
| Bore Tolerance | +0.050 mm / +0.012 mm |
| Clearance Diameter (c) Max | 47.4 mm |
| Finish Specification | Sulfuric Anodized MIL-A-8625 Type II, Class 2 and ASTM B580 Type B Black Anodize |
| Forged Clamp Screw | M6 x 16 |
| Hex Wrench Size | 5.0 mm |
| Material Specification | 2024-T351 Aluminum Bar |
| Number Of Screws | 2 ea |
| Outer Diameter (od) | 40 mm |
| Recommended Gap | 1.59 mm |
| Recommended Shaft Tolerance | +0.000 mm / -0.013 mm |
| Screw Finish | Bright |
| Screw Location (r) | 14.73 mm |
| Screw Material | 18-8 300 Series Stainless Steel |
| Seating Torque | 9.6 Nm |
| Temperature | -40°F to 200°F (-40°C to 93°C) |
| Width (w) | 15 mm |
| Width Tolerance | +0.076 mm / -0.254 mm |
| Ship weight (kg) | 0.04 |
| Ship height (cm) | 4 |
| Ship length (cm) | 4 |
| Ship width (cm) | 1.5 |
| Country of Origin | US |
