| B1 Max Shaft Penetration | 1.634 in (41.5 mm) |
| B2 Max Shaft Penetration | 1.634 in (41.5 mm) |
| Bore (b1) | 1.2500 in |
| Bore Tolerance | +0.0020 in / +0.0005 in (+0.050 mm / + 0.012 mm) |
| Clearance Diameter (c) Max | 2.311 in (58.7 mm) |
| Finish Specification | Bright, No Plating |
| Forged Clamp Screw | M6 |
| Full Bearing Support Required? | No |
| Hex Wrench Size | 5.0 mm |
| Length (l) | 3.268 in (83.0 mm) |
| Material Specification | Type 303 Austenitic, Non-Magnetic Bar |
| Maximum Speed | 4,000 RPM |
| Moment Of Inertia | 1.472293 lb-in |
| Number Of Screws | 4 ea |
| Nypatch Anti-vibration Hardware? | Yes |
| Outer Diameter (od) | 2.087 in (53 mm) |
| Rated Torque | 1327 in-lb (150 Nm) |
| Recommended Shaft Tolerance | +0.0000 / -0.0005 " (+0.000 / -0.013 mm) |
| Screw Finish | Bright |
| Screw Location (r) | 0.823 in (20.9 mm) |
| Screw Material | 18-8 300 Series Stainless Steel with |
| Seating Torque | 9.6 Nm |
| Small Bore (b2) | 30 mm |
| Temperature | -40°F to 350°F (-40°C to 176°C) |
| Zero-backlash? | Yes |
| Ship weight (kg) | 0.91 |
| Ship height (cm) | 5.3 |
| Ship length (cm) | 8.3 |
| Ship width (cm) | 5.3 |
| Country of Origin | US |
