| 3 | $256.62 |
| Angular Misalignment | 2.0° |
| Axial Motion | 0.76 mm |
| B1 Max Shaft Penetration | 40.2 mm |
| B1 Min Shaft Penetration | 19.1 mm |
| B2 Max Shaft Penetration | 40.2 mm |
| B2 Min Shaft Penetration | 19.1 mm |
| Balanced Design | Yes |
| Bellows Attachment Method | Epoxy |
| Bore (B1) | 35 mm |
| Bore Tolerance | +0.03 mm / -0.00 mm |
| Dynamic Torque Non-Reversing | 52.25 Nm |
| Dynamic Torque Reversing | 26.13 Nm |
| Finish Specification | Sulfuric Anodized MIL-A-8625 Type II, Class 2 and ASTM B580 Type B Black Anodize |
| Forged Clamp Screw | M8 |
| Full Bearing Support Required? | Yes |
| Hex Wrench Size | 6.0 mm |
| Hub Width (LH) | 30.48 mm |
| Length (L) | 87.4 mm |
| Length Tolerance | +/- 0.76 mm |
| Material Specification | Hubs: 2024-T351 Aluminum Bar |
| Maximum Speed | 10,000 RPM |
| Moment of Inertia | 4.222 |
| Number of Screws | 2 ea |
| Outer Diameter (OD) | 69.9 mm |
| Parallel Misalignment | 0.30 mm |
| Recommended Hex Key | Metric Hex Keys |
| Recommended Shaft Tolerance | +0.000 mm / -0.013 mm |
| Screw Finish | Black Oxide |
| Screw Material | Alloy Steel |
| Seating Torque | 39 Nm |
| Small Bore (B2) | 22 mm |
| Static Torque | 104.5 Nm |
| Temperature | -40°F to 200°F (-40°C to 93°C) |
| Torque Wrench | TW:BT-4C-3/8-345 |
| Torsional Stiffness | 237 Nm/Deg |
| Zero-Backlash? | Yes |
| Ship weight (kg) | 0.57 |
| Ship height (cm) | 6.99 |
| Ship length (cm) | 8.74 |
| Ship width (cm) | 6.99 |
| Country of Origin | US |
