| 1000 | Request Quote |
| Body Length L2 | 8 mm |
| End Spring Load | 16 N |
| Hex Nut Size | 12 mm |
| Hole Tolerance | +0.030/-0 mm |
| Hub Diameter Dh | 18 mm |
| Initial Spring Load | 6 N |
| Knob Diameter D1 | 25 mm |
| Knob Height H1 | 20 mm |
| Overall Length L1 | 34 mm |
| Pin Diameter D2 | 4.73 mm |
| Pin Length L3 | 6 mm |
| Plunger Pin Tolerance | +0.03/+0.08 mm |
| Temperature | -40°F to 230°F (-40°C to 110°C) |
| Thread (th) | 3/8 in - 24 TPI |
| Ship weight (kg) | 0.02 |
| Ship length (cm) | 3.4 |
| Country of Origin | DE |
