RULAND MANUFACTURING LV-MSP-32-FZ Quick Clamping Shaft Collar, 32 mm Bore Dia, Round, Carbon Steel, Black

Item: CT9LAE
Model: LV-MSP-32-FZ
13 In Stock

Ships within 2 days via

Handle Color
Collar Material Finish
£138.96
5.00% off
£132.02/unit (Inc. VAT)
Trade Prices Available
Request Quote

Payment

Specifications

Bore Dia. 32 mm
Bore Tolerance 0.012 mm to 0.5 mm
Bore Type Round
Center To Lever Top 40.8 mm
Collar Construction 2-Piece
Collar Material Carbon Steel
Collar Material Finish Zinc Plated
Collar Material Grade 1215
Collar Outside Diameter 54 mm
Collar Width 15 mm
Construction Two Piece
For Shaft Dia. 32 mm
For Shaft Diameter 32 mm
For Shaft Type Round
Handle Color Black
Handle Material Zinc
Handle Material Finish Powder Coated
Lever Length 45 mm
Outside Dia. 54 mm
Resistance Properties Corrosion Resistant
Screw Location From Center 21.49 mm
Screw Material Stainless Steel
Screw Material Grade Grade 303
Screw Thread Size M6
Shaft Locking Type Clamp On
Shaft Tolerance -0.013 mm to 0 mm
System Of Measurement Metric

Product Details

Shipping Information

Height 2.54
Length 2.54
Width 2.54
Weight 0.193000
