| 1000 | Request Quote |
| Body Length L2 | 26 mm |
| End Spring Load | 38 N |
| Hex Nut Size | 17 mm |
| Hole Tolerance | +0.015/-0 mm |
| Initial Spring Load | 9.5 N |
| Knob Diameter D1 | 28 mm |
| Knob Height H1 | 24 mm |
| Nut Height Hn1 | 8 mm |
| Overall Length L1 | 58 mm |
| Pin Diameter D2 | 10 mm |
| Pin Length L3 | 12 mm |
| Plunger Pin Tolerance | -0.02/-0.05 mm |
| Temperature | -40°F to 230°F (-40°C to 110°C) |
| Thread (th) | 5/8 in - 11 TPI |
| Ship weight (kg) | 0.06 |
| Ship length (cm) | 5.8 |
| Country of Origin | DE |
