| Alarm: | Low voltage, counting value composition error, overflow error, tolerance limit setting error |
| Battery Life: | Approx. 7000 hours |
| Contact Point: | Carbide ball, thread: No.4-48UNF |
| Counting Direction Switchable: | Yes |
| Data/hold: | Yes |
| Digimatic Data Output: | Yes |
| Digital Scale: | Electrostatic capacitance type absolute linear encoder |
| Digital Step: | 0.00005"/0.0005"/0.001 mm/0.01 mm |
| Digital/analog: | Digital |
| Display: | LCD, character height: 6.2 mm |
| Externalpreset / Zero: | Yes |
| Functions: | ANSI/AGD type |
| Go/±ng Judgement: | Yes |
| H Mpe (hysteresis): | 0.0001"/0.002 mm |
| Inch-metric: | Inch/Metric |
| Inch/metric Switchable: | Yes |
| Max. Permissible Errore Mpe (total Range): | ±0.00012"/0.003 mm |
| Max. Response Speed: | Unlimited |
| Measuring Force Mpl: | x89¤2 N |
| Measuring Force: | x89¤2 N N |
| On/off: | Yes |
| Power Supply: | 1 battery SR44 |
| Protection: | IP66 |
| R Mpe (repeatability): | 0.0001"/0.002 mm |
| Range: | 0.2"/5.08 mm |
| Selectable Resolution: | Yes |
| Stem X88x85: | 9.52 mm |
| Type: | ASME/ANSI/AGD Standard |
| Ship height (cm) | 7.62 |
| Ship length (cm) | 20.32 |
| Ship width (cm) | 11.43 |
