| Ambient Temp. | 40°C |
|---|---|
| Application | General Application |
| Bearing Type | Ball |
| Bearings | Ball |
| Cc Number | CC003A |
| Duty | Continuous |
| Duty Cycle | Continuous |
| Efficiency | 95% |
| Efficiency Group | Premium |
| Frame | 315S |
| Frame Material | Cast Iron |
| Frequency | 50/60 Hz |
| Full Load Amps | 246/123A |
| Full Load Amps @ 50hz | 220/110A |
| Hp | 100 hp |
| Hp @ 50hz | 100 hp |
| Insulation Class | Class F |
| Inverter Rated | Yes |
| Length Less Shaft | 1036 mm |
| Manufacturers Warranty Length | 1 yr. |
| Max. Ambient Temp. | 40°C |
| Motor Application | General Application |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Frame Material | Cast Iron |
|---|---|
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1.15 |
| Motor Shaft Rotation | Clockwise/Counter Clockwise |
| Motor Type | Three Phase |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 1190 RPM |
| Nema Design | N |
| No. Of Speeds | 1 |
| Nominal Efficiency | 95% |
| Number Of Speeds | 1 |
| Overall Length | 1206 mm |
| Phase | 3 |
| Service Factor | 1.15 |
| Shaft Dia. | 80 mm |
| Shaft Length | 170 mm |
| Standard Logo | ce.png, ul.png |
| Standards | Ce, Ul Recognized |
| Thermal Protection | None |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 230/460V AC |
| Motor Thermal Protection | None |
| Height | 95 |
|---|---|
| Length | 129.01 |
| Width | 73 |
| Country Of Origin | IN |
|---|---|
| Weight | 814.500000 |
| Style | Model | Voltage | Phase | Frequency | Full Load Amps | Motor Type | Service Factor | Nameplate Rpm | Hp | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | U3E3DCR | 230/460V AC | 3 | 50/60 Hz | 9.1/4.5A | Three Phase | 1.25 | 1200 RPM | 3 hp | 1,002.62 | |
| B | 2TJ12 | 230V AC | 1 | 60 Hz | 22A | Capacitor Start/Run | 1 | 1740 RPM | 5 hp | 1,641.05 | |
| C | 182TTFBD6079 | 230/460V AC | 3 | 60 Hz | 4.6/2.3A | Three Phase | 1.15 | 1175 RPM | 1 1/2 hp | 1,350.15 | |
| D | 5GD60 | 115/208-230V AC | 1 | 60 Hz | 11.4/5.7A | Capacitor Start | 1.15 | 1725 RPM | 3/4 hp | 438.89 | |
| E | 5K596 | 115V AC | 1 | 60 Hz | 8A | Split Phase | 1 | 1725 RPM | 1/2 hp | 321.02 | |
| E | 5K618 | 115V AC | 1 | 60 Hz | 7.2/5A | Split Phase | 1 | 1725/1140 RPM | 1/4 hp, 1/2 hp | 428.59 | |
| F | 5K968 | 230V AC | 1 | 60 Hz | 23A | Capacitor Start/Run | 1 | 1745 RPM | 5 hp | 1,890.57 |
