| Item | HVAC Motor |
| Ambient Temp. | 40°C |
| Duty Cycle | Continuous |
| Enclosure Type | Totally Enclosed Fan Cooled |
| Frame | 56 |
| Frequency | 60 Hz |
| Full Load Amps | 8A |
| Hp | 1/2 hp |
| Insulation Class | Class B |
| Max. Ambient Temp. | 40°C |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Position | All Angle |
| Motor Mounting Type | Rigid Base |
| Motor Shaft Rotation | Selective CCW |
| Motor Thermal Protection | No |
| Motor Type | Split Phase |
| Mounting Type | Resilient Base |
| Nameplate Rpm | 1725 RPM |
| Number Of Speeds | 1 |
| Phase | 1 |
| Service Factor | 1.25 |
| Shaft Dia. | 0.63" |
| Shaft Length | 1 22/25" |
| Shaft Orientation | Horizontal/Vertical |
| Thermal Protection | None |
| Voltage | 115V AC |
| Ship weight (kg) | 9.45 |
| Ship height (cm) | 24.13 |
| Ship length (cm) | 38.46 |
| Ship width (cm) | 25.88 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Full Load Amps | HP | Item | Service Factor | Thermal Protection | Voltage | Price | |
|---|---|---|---|---|---|---|---|---|---|
 |
5KH35MN56X | 5.9 | 1/3 | HVAC Motor | 1.0 | Automatic | 115 | £368.90 | |
 |
5KC42GN0309X | 8.6/4.3 | 1/2 | General Purpose Motor | 1.15 | Automatic | 115/230 | £903.38 |
