INSULTAB HS-614 3/16 Blk 48 Heat Shrink Tubing Food-grade 20-18awg x 48in, 5PK
Item: AE2DEY
Model: HS-614 3/16 Blk 48
10 In Stock
Ships within 2 days via
5.00% off
£38.08/pkg. of 5
(Inc. VAT)
Trade Prices Available
Request Quote
Payment
Delivery
Specifications
| Adhesive Lined | No |
|---|---|
| Cable Size | 20 AWG to 18 AWG |
| Color | Black |
| Dielectric Strength | 1800V |
| Features | Environmentally Friendly |
| Flame Retardant | No |
| I.d. After Shrinking | 0.09" |
| I.d. Before Shrinking | 0.19" |
| Length | 4 ft. |
| Length (straight Wireway) | 4 ft. |
| Material | Acrylate Olefin |
| Max. Temp. Rating | 250°F |
| Min. Shrink Temp. | 250°F |
| Min. Temp. Rating | -67°F |
| Package Style | Individual Pieces |
| Shrink Ratio | 2:1 |
|---|---|
| Shrink Temp. | 212°F |
| Shrink Tubing Adhesive Lined | No |
| Shrink Tubing I.d. Before Shrinking | 0.187" |
| Shrink Tubing Length | 4 ft. |
| Shrink Tubing Properties | Food Grade |
| Shrink Tubing Wall Type | Thin Wall |
| Temp. Range | -67°F to +250°F |
| Tubing Wall Type | Thin Wall |
| Use With Wire Size | 20 AWG to 18 AWG |
| Wall Thickness After Shrinking | 0.02" |
| Wall Type | Thin Wall |
| Wire Size | 20 AWG to 18 AWG |
| standard | USFDA REG.C.F.R.177.1330 |
Product Details
Heat Shrink Tubing, Food Grade
Shipping Information
| height | 5.08 |
|---|---|
| length | 124.46 |
| width | 5.08 |
| hs code | 3926909980 |
|---|---|
| country of origin | US |
| weight | 0.045000 |
Related Products
| Style | Model | I.d. Before Shrinking | I.d. After Shrinking | Wall Thickness After Shrinking | Use With Wire Size | Package Style | Wire Size | Cable Size | Color | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | HS-614 3/32 Blk 6 | 0.09" | 0.05" | 0.02" | 28 AWG to 26 AWG | Individual Pieces | 28 AWG to 26 AWG | 28 AWG to 26 AWG | Black | 8.87 | |
| A | HS-614 1/8 Blk 6 | 0.13" | 0.06" | 0.02" | 24 AWG to 22 AWG | Individual Pieces | 24 AWG to 22 AWG | 24 AWG to 22 AWG | Black | 9.36 | |
| A | HS-614 3/16 Blk 6 | 0.19" | 0.09" | 0.02" | 20 AWG to 18 AWG | Individual Pieces | 20 AWG to 18 AWG | 20 AWG to 18 AWG | Black | 9.46 | |
| A | HS-614 1/4 Blk 6 | 1/4" | 0.13" | 0.03" | 16 AWG to 12 AWG | Individual Pieces | 16 AWG to 12 AWG | 16 AWG to 12 AWG | Black | 10.43 | |
| A | HS-614 3/8 Blk 6 | 0.38" | 0.19" | 0.03" | 12 AWG to 8 AWG | Individual Pieces | 12 AWG to 8 AWG | 12 AWG to 8 AWG | Black | 11.10 | |
| A | HS-614 1/2 Blk 6 | 1/2" | 1/4" | 0.03" | 6 AWG to 1 AWG | Individual Pieces | 6 AWG to 1 AWG | 6 AWG to 1 AWG | Black | 12.13 | |
| A | HS-614 3/32 Blk 48 | 0.09" | 0.05" | 0.02" | 28 AWG to 26 AWG | Individual Pieces | 28 AWG to 26 AWG | 28 AWG to 26 AWG | Black | 20.56 |
