GROVE GEAR GRL8212054.00 GRL-DM821-150-R1-56 Double Reduction Reducer, 150:1 Ratio, 1 Inch Output Diameter, Cast Iron
Item: AY9BMC
Model: GRL8212054.00
In Stock
Get it by Wednesday, Apr 15
We deliver to your doorstep under DAP terms. Customs clearance is for your account
Trade Prices Available
Request Quote
Payment
Delivery
Specifications
| Center Distance | 2.06" |
|---|---|
| Frame | 56C |
| Gear Type | Double Worm |
| Housing Material | Cast Iron |
| Input Rpm | 1750 RPM |
| Input Style | C Face Coupled |
| Max. Input Hp | 0.366 hp |
| Mounting Type | Base |
| No. Of Gear Reductions | 2 |
| Output Diameter | 1" |
| Output Hp | 0.238 hp |
| Output Rpm | 11.7 RPM |
| Output Shaft | Shaft |
|---|---|
| Output Shaft Assembly Code | DM |
| Output Shaft Orientation | R1 |
| Output Torque | 1284 lbs.-in. |
| Overhung Load | 1175 lbs. |
| Product Line | GR Series - Ironman Worm Gear Reducers |
| Reducer | Worm - Right Angle |
| Reduction Type | Double |
| Series | GR Series |
| Series Style | GRL-DM |
| Tap Depth | 0.63" |
| Thread Type | Coarse |
Product Details
Reducer
Shipping Information
| height | 2.54 |
|---|---|
| length | 2.54 |
| width | 2.54 |
|---|---|
| weight | 22.950000 |
