EATON M22-DGH-R-K10 Flush Push Button Operator, Non-Illuminated, Flush Profile, Non-Metallic, 22 mm, Green
Item: BH4RER
Model: M22-DGH-R-K10
20 In Stock
Ships within 2 days via
5.00% off
£63.08/unit
(Inc. VAT)
Trade Prices Available
Request Quote
Payment
Delivery
Specifications
| Ac Contact Rating | 6A @ 240V |
|---|---|
| Action | Momentary |
| Actuator Function | Momentary |
| Actuator Type | Button, extended with guard |
| Bezel | Silver |
| Button Color | Red |
| Contact Configuration | 1 NO |
| Dc Contact Rating | 3A @ 24V |
| Display Qty | 1 |
| Features | Field Conversion From Momentary To Maintained Can Be Done, Includes Contact Block Mounting Adapter |
| Head Material | Plastic |
| Head/lens Color | Red |
| Height | 1" |
| Illumination | Non-illuminated |
| Ip Rating | IP67, IP69K |
| Length | 1 1/2" |
| Manufacturer Warranty Length | 1 yr. |
| Nema Enclosure Rating | NEMA 1, NEMA 2, NEMA 3, NEMA 3R, NEMA 4, NEMA 4X, NEMA 12, NEMA 13 |
| Number Of Operators | 1 |
| Operating Temperature - Maximum | 158°F |
|---|---|
| Operating Temperature - Minimum | -13°F |
| Operator Illumination | Non Illuminated |
| Operator Material | Plastic |
| Overall Depth | 2.56" |
| Overall Height | 1" |
| Overall Width | 1" |
| Panel Mounting Hole Diameter | 22 mm |
| Product Type | Push Button Operators |
| Push Button Style | Flush |
| Resistance Properties | Corrosion Resistant |
| Series | M22 Series |
| Standard Logo | ccc.png,csa.png |
| Terminal Connection | Spring Cage |
| Type | Pushbutton |
| Warranty | Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first. |
| Width | 1" |
| standard | BUREAU VERITAS, CCC, CE, CSA, GOST-R, LLOYD'S REGISTER, UL LISTED |
Product Details
Push Button Operator
Shipping Information
| height | 2.54 |
|---|---|
| length | 3.81 |
| width | 2.54 |
| country of origin | US |
|---|---|
| weight | 0.031500 |
