EATON HT8GDBF1Q1L1 Illuminated PushButton, Transfmr, Blue, 2NO/2NC

Item: BH3NFE
Model: HT8GDBF1Q1L1
19 In Stock

Ships within 2 days via

£498.41
5.00% off
£473.48/unit (Inc. VAT)
Trade Prices Available
Request Quote

Payment

Specifications

Ac Contact Rating 10A @ 600V
Action Momentary
Actuator Type Extended
Bezel Chrome
Bezel Material Chrome
Contact Configuration 2 NO, 2 NC
Contact Form 2NO/2NC
Dc Contact Rating 5A @ 250V
Display Qty 1
Features Allen Bradley Pushbutton Panel Compatible
Head Material Metal
Head/lens Color Blue
Height 1 2/5"
Illumination Illuminated
Ip Rating IP65
Lamp Bulb Type LED
Lamp Module Type Transformer
Lamp Voltage - Maximum 120V AC/DC
Length 6.55"
Lens Color Blue
Light Unit Voltage 120V AC/DC
Manufacturer Warranty Length 1 yr.
Mechanical Operating Durability 1 x 10^7
Nema Enclosure Rating NEMA 12, NEMA 13, NEMA 3, NEMA 3R, NEMA 4, NEMA 4X
Number Of Indicator Lights 0
Number Of Operators 1
Operating Mode Momentary
Operating Temperature - Maximum 140°F
Operating Temperature - Minimum 10°F
Operator Illumination Illuminated
Operator Material Metal
Operator Voltage Rating - Maximum 28V
Overall Depth 6.55"
Overall Height 1 2/5"
Overall Width 2"
Panel Mounting Hole Diameter 30 mm
Product Type Push Button Operators
Push Button Style Extended
Resistance Properties Oil And Grease Resistant, Watertight
Series Ht800 Series
Standard Logo csa.png,ul.png
Standards Ce, Csa, Ul Listed
Terminal Connection Screw Clamp
Type 30.5 mm, Watertight/Oiltight-HT800
Warranty 1 yr.
Width 2"

Product Details

Pushbutton

Shipping Information

height 3.56
length 16.64
width 5.08
country of origin US
weight 0.315000
