EATON FG3125WD05Z05 Molded Case Circuit Breaker, F-Frame, Type Fg, 3-Pole, 125A, 600 Vac, 60 Hz
Item: BH9PGC
Model: FG3125WD05Z05
In Stock
Get it by Wednesday, Apr 15
£2817.59/unit
(Inc. VAT)
Trade Prices Available
Request Quote
Payment
Delivery
Specifications
| Amperage Rating | 125A |
|---|---|
| Circuit Breaker Frame Type | Complete Breaker |
| Circuit Breaker Type | FG |
| Class | Engine Generator |
| Frame | F |
| Frequency Rating | 60 Hz |
| Functions | Reverse |
| Generator Rating | 45 KVA/36 kW at 240V, 90 KVA/72 kW at 480V, 113 KVA/90 kW at 600V |
| Height | 5" |
| Interrupt Rating | 18 kAIC at 240V AC, 14 kAIC at 480V AC |
| Length | 7" |
| Line | KPR1AM |
|---|---|
| Number Of Poles | 3 |
| Pickup | Fixed |
| Prod Load | 3TA225FD |
| Standard Logo | csa.png,iec.png,ul.png |
| Terminals | Line Side End Cap, Optional Load Side |
| Trip Type | Fixed Thermal, Fixed Magnetic |
| Voltage | 600V AC |
| Warranty | Eaton Selling Policy 25-000, One (1) Year From The Date Of Installation Of The Product Or Eighteen (18) Months From The Date Of Shipment Of The Product, Whichever Occurs First. |
| Width | 5" |
Product Details
Circuit Breaker
Shipping Information
| height | 12.7 |
|---|---|
| length | 17.78 |
| width | 12.7 |
| country of origin | US |
|---|---|
| weight | 1.800000 |
