BOSTON GEAR NJ14B-1 1/8 Spur Gear, 6 Diametral Pitch, 14 1/2 Deg. Pressure Angle, 14 Teeth, Steel
Item: AK3BYW
Model: NJ14B-1 1/8
27 In Stock
Ships within 2 days via
£269.52/unit
(Inc. VAT)
Trade Prices Available
Request Quote
Payment
Specifications
| Bore Dia. | 1 1/8" |
|---|---|
| Bore Type | Bored To Size |
| Diametral Pitch | 6 |
| Face Width | 1 1/2" |
| Hardened Teeth | Without Hardened Teeth |
| Hub Dia. | 1.78" |
| Keyway | With Keyway |
| Length Through Bore | 2 3/8" |
| Material | Steel |
| Maximum Rated Torque | 618 N-m @ 1200 RPM |
| No. Of Teeth | 14 |
| Outer Dia. | 2.67" |
| Pitch Dia. | 2.333" |
|---|---|
| Pressure Angle | 14.5° |
| Rated Torque [max] | 618 N-m @ 1200 RPM |
| Set Screw | Yes |
| Set Screw Size | 1.125 |
| Torque At 1200 Rpm | 618 lbs.-in. |
| Torque At 1800 Rpm | 485 lbs.-in. |
| Torque At 200 Rpm | 1142 lbs.-in. |
| Torque At 300 Rpm | 1053 lbs.-in. |
| Torque At 600 Rpm | 853 lbs.-in. |
| Torque At 900 Rpm | 717 lbs.-in. |
| Type | A |
Product Details
Spur Gear
Shipping Information
| height | 2.54 |
|---|---|
| length | 2.54 |
| width | 2.54 |
|---|---|
| weight | 0.855400 |
Related Products
| Style | Model | Diametral Pitch | Number Of Teeth | Bore Dia. | Hub Dia. | Pitch Dia. | Hub Projection | Outside Dia. | Keyway | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | NJ12 B | 6 | 12 | 1" | 1 11/25" | - | 0.88" | 2.333" | No | 147.79 | |
| A | NJ16 B | 6 | 16 | 1" | 2.13" | 2.667" | 0.88" | 3" | No | 192.22 | |
| A | NJ18 B | 6 | 18 | 1" | 2.45" | 3" | 0.88" | 3.333" | No | 232.17 | |
| A | NJ24A | 6 | 24 | 1 1/8" | 3" | 4" | 0.88" | 4.333" | No | 350.00 | |
| A | NJ30A | 6 | 30 | 1 1/8" | 4" | 5" | 0.88" | 5.333" | No | 421.63 | |
| B | NJ11B | 6 | - | - | - | - | - | - | No Kwy Or Setscrew | 146.78 | |
| C | NJ14B | 6 | 14 | - | - | - | - | - | No Kwy Or Setscrew | 163.47 |
