APPROVED VENDOR M38130.360.0001 Flat Washer, M36 Bolt Size, Std, 37mm I.D., 66mm O.D., 2PK

Item: AB7DYV
Model: M38130.360.0001
14 In Stock

Ships within 2 days via

£4.64
5.00% off
£4.42/pkg. of 2 (Inc. VAT)
Trade Prices Available
Request Quote

Payment

Delivery

Specifications

Dimensional Standards Din 125-1A
Finish Zinc Plated
Fits Bolt Sizes M36
Flat Washer Type Standard
For Screw Size M36
Grade Grade 2
Inside Dia. 37 mm
Inside Diameter Tolerance 1.457" to 1.481"
Made In North America No
Material Steel
Material Grade/class Ungraded
Material Quality Standards Not Rated
Maximum Temperature 350°C
Maximum Thickness 5 mm
Minimum Temperature -58°C
Minimum Thickness 5 mm
Outside Dia. 66 mm
Outside Diameter Tolerance 2.551" to 2.598"
Reach Compliant Yes
Removable Yes
Rockwell Hardness 140Hv
Rohs Compliant Yes
System Of Measurement Metric
Thickness 5 mm
Thickness Tolerance 0.173" to 0.22"
Washer Type Standard Washer

Product Details

Flat Washer

Shipping Information

height 1.27
length 16.99
width 16.38
hs code 7318220000
country of origin TW
weight 0.182700
