| Ansi Code | F2010.B.200.Z12.08.R756M |
|---|---|
| Arbor Dia. | 2.362" |
| Coolant Fed | Non Coolant Through |
| Cutting Application | Shoulder Milling |
| Cutting Depth | 0.331" |
| Iso Number | F2010.B.200.Z12.08.R756M |
| Max. Speed | 4200 RPM |
| Min. Cutting Dia. | 7.874" |
| Number Of Inserts | 12 |
| Overall Length | 2 12/25" |
|---|---|
| Side Cutting Edge Angle | 90° |
| Standards | Iso 6462-C (4 Bolts) |
| Connection Dia. | 2.362" |
| Cutting Edge Dia. | 7.874" |
| Cutting Edge Length | 0.331" |
| Max. Projection Length | 2 12/25" |
| No. Of Indexable Inserts | 12 |
| No. Of Teeth | 12 |
| Height | 2.54 |
|---|---|
| Length | 6.3 |
| Width | 2.54 |
| Country Of Origin | NL |
|---|---|
| Weight | 8.234100 |
| Style | Model | Coolant Fed | Overall Length | Arbor Dia. | Side Cutting Edge Angle | Max. Cutting Dia. | Insert Shape | Depth Of Cut | Cutting Depth | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | F5141.B40.160.Z13.12 | Coolant Through | 63 mm | 40 mm | 90° | 160 mm | - | 0.472" | - | 2,475.89 | |
| B | F5141.UB38.152.Z13.12 | Coolant Through | 2.48" | 1 1/2" | 90° | 6" | - | 0.472" | - | 2,475.89 | |
| C | M5130-050-B22-06-15 | Coolant Through | 1.575" | 0.866" | 90° | - | - | - | 0.591" | 933.25 | |
| D | M5130-063-B22-11-05 | Coolant Through | 1.575" | 0.866" | 90° | - | - | - | 0.197" | 1,264.94 | |
| E | M2136-063-B22-08-06 | Non Coolant Through | 1.969" | 0.866" | 90° | - | - | - | 0.256" | 1,716.37 | |
| C | M5130-054-B22-03-15 | Coolant Through | 1.575" | 0.866" | 90° | - | - | - | 0.591" | 811.02 | |
| D | M5130-063-B22-14-05 | Coolant Through | 1.575" | 0.866" | 90° | - | - | - | 0.197" | 1,335.95 |
