UNITED BRASS WORKS 294001 Gate Valve 3/4 Inch Fnpt Bronze

Item: AD6FCH
Model: 294001
27 In Stock

Ships within 2 days via

£2294.42
5.00% off
£2179.7/unit (Inc. VAT)
Trade Prices Available
Request Quote

Payment

Delivery

Specifications

Body Material Bronze
Bonnet Material Brass
Bonnet Style Union
Connection Size - Side 1 3/4"
Connection Size - Side 2 3/4"
Connection Type FNPT
Disc Material Stainless Steel
For Media Gas, Oil, Steam, Water
Globe Valve Body Type Angle
Handle Diameter 1.44"
Handle Height 8.15"
Handle Material Ductile Iron
Handle Type Wheel
Inlet To Outlet Length 1.656"
Max. Fluid Temp. 406°F
Max. Pressure (cwp) 390 psi
Max. Pressure (steam) 390 psi
Max. Water Pressure 385 psi
Media Temp. Range 500°F to 500°F
Media Temperature Range 500°F to 500°F
Pipe Size 3/4"
Seat Material Stainless Steel
Stem Material Brass
Stem Type Rising
Top Of Handle To Inlet Center 7.781"
Valve Series 364 Series
Valve Stem Type Rising
Wedge Material Stainless Steel
standard MSS-SP-80-2013

Product Details

Gate Valve

Shipping Information

height 11.43
length 20.57
width 15.49
hs code 8481801070
country of origin US
weight 1.552500
