SMC VALVES

See our 858 reviews on trustpilot

SMC VALVES SY3120-3LOZ-N7 Valve

Item: AL3UNT
Model: SY3120-3LOZ-N7
11 In Stock

Ships within 2 days via

£85.97/unit (Inc. VAT)
Trade Prices Available
Request Quote

Payment

Specifications

Actuation [Single] Single
application Single Unit
Body Material Zinc
Bracket No Bracket
Bracket Type Without Bracket
Driving Type 0.15 to 0.7
Flow Coefficient 0.18
Flow Direction 4-Way
Indicator Light/surge Voltage Suppressor With Indicator Light, Surge Voltage Suppressor
Lead Wire Electrical Entry L Plug Connector With Lead Wire (Length: 300 mm)
Manual Operation Type Non-Locking Push
Max. Operating Pressure 101 psi
Mounting Orientation Direct
No. Of Port 5
No. Of Positions 2
Number Of Solenoids Single
Operating Medium Air
Operating Temp. Range 14°F to 122°F
Overall Height 40.6 mm
Overall Length 79 mm
Overall Width 10.8 mm
Pipe Port Type One Touch Plumbing
Piping Type Body Ported
Port Size One Touch Fitting For 1/4"
Port Sizes 1/4" BSPT
Pressure Rating (mpa) 0.15 MPa to 0.7 MPa
Seal Material Rubber
Series SY Series
Solenoid Electrical Entry L Plug
Solenoid Power Consumption 0.35 W
Solenoid Supply Frequency 50/60 Hz
Solenoid Supply Voltage 110-115V AC
Thread Standard RC
Type Solenoid Valve
Valve Function Spool
Valve Positions 2 Position Exhaust
Valve Series SY3000 Series
Voltage 110V AC
Voltage Suppressor With Light, Surge Voltage Suppressor

Product Details

Shipping Information

height 5.08
length 7.62
width 5.08
weight 0.900000
