SEALMASTER SF-28TC 705814 Flange Block Bearing, 4 Bolt Square Flange Block, 1.75 Inch Bore, 5.8 Inch Bolt Dia

Item: BE7JUQ

Model: SF-28TC

In Stock

Get it by Friday, Apr 17

£276.46/unit (Inc. VAT)

Trade Prices Available

Request Quote

Payment

Delivery

Specifications

Ability To Relubricate	Yes
Bearing Insert Finish	Black Oxide
Bearing Insert Material	Steel
Bearing Insert Material Grade	52100
Bearing Insert Type	Standard Duty
Bolt Size	9/16"
Bolt Spacing	4 1/8"
Bore Dia.	1 3/4"
Bore Shape	Straight
Cage Material	Polyphenylene Sulfide
Cage Type	Land Riding Retainer
Dynamic Load Capacity	7901 lbs.
End Cap	No
Fixed Vs. Expansion	Fixed
Foot Height	14/25"
Grease Fitting Thread Size	1/4"-28
Housing Backside Inner Diameter	3.88"
Housing Coating	Powder Coated
Housing Color	Black
Housing Construction	One Piece
Housing Material	Cast Iron
Housing Style	Flange Block
Housing Type	Flange, Four Bolt

Htc	8483.20.4040
Inner Race Heat Treat Method	Zone Hardened
Inner Ring Outside Diameter	2.307"
Insert	2-112TC
Length Through Bore	2.06"
Locking Collar Outside Diameter	3"
Lubrication Type	Lithium Complex NLGI 2 Grease
Max. Operating Temperature	220°F
Max. Speed	3800 RPM
Misalignment Capability	-2° to +2°
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Overall Height	2.167"
Overall Length	5.38"
Overall Width	5.38"
Pilot Configuration	No Pilot
Radial Clearance	Standard
Rolling Element	Ball Bearing
Seal Type	Single Lip Contact Seal
Shaft Locking Type	Concentric
Size Code	2-111
Static Load Rating	5139 lbs.

Country Of Origin	US
Weight	2.727000

Style	Model	Housing Material	Bore Dia.	Number Of Mounting Holes	Price (ex. VAT)	Cart
A	SF-16 HI	-	-	-	856.90
B	SF-24	Cast Iron	1 1/2"	-	405.03
C	SF-206	Cast Iron	30 mm	-	275.29
A	SF-31T CSK	Cast Iron	-	-	1,145.94
D	SF-47	Cast Iron	2 15/16"	-	1,001.40
E	SF-11	Cast Iron	11/16"	-	-	RFQ
F	SF-31	Cast Iron	1 15/16"	-	503.51
