SEALMASTER RFPA 307 551930 Flange Block Bearing, 4 Bolt Round Flange Cartridge, 3.43 Inch Bore, 8.6 Inch Bolt Dia
Item: BF8BFJ
Model: RFPA 307
In Stock
Get it by Friday, Apr 17
£3059.93/unit
(Inc. VAT)
Trade Prices Available
Request Quote
Payment
Delivery
Specifications
| Ability To Relubricate | Yes |
|---|---|
| Bearing Insert Finish | Uncoated |
| Bolt Center Dia. | 8 5/8" |
| Bolt Size | 3/4" |
| Bore Dia. | 3 7/16" |
| Bore Shape | Straight |
| Centerline To Front Face | 2.563" |
| Collar Outer Dia. | 5 1/2" |
| Collar Outer Diameter | 5 1/2" |
| Duty Series | Standard |
| Duty/series | Standard Series |
| End Cap | No |
| Expansion | Non Expansion Bearing Fixed |
| Fixed Vs. Expansion | Fixed |
| Foot Height | 7/8" |
| Grade | Grade 52100 |
| Grease Fitting Thread Size | 1/8" |
| Grease Fitting Thread Type | NPT |
| Height | 6.63" |
| Housing Base | Solid |
| Housing Color | Gray |
| Housing Construction | Split Two Piece |
| Housing Material | Cast Iron |
| Housing Outside Dia. | 10 1/4" |
| Housing Outside Diameter | 10 1/4" |
| Housing Style | Flange Block |
| Htc | 8483.20.4080 |
| I.d. | 3 7/16" |
|---|---|
| Inner Race Heat Treat Method | Case Carburized Inner Ring |
| Inner Race Length | 4.188" |
| Insert Material | Steel |
| Insert Material Grade | 52100 |
| Insert Number | RCIA-307 |
| Internal Clearance | Standard |
| Length | 11" |
| Locking Device | Single Set Screw |
| Locking Type | Collar Mount |
| Lubrication Type | Lithium, EP, NLGI |
| Max. Speed | 1500 RPM |
| Misalignment Type | Static Only |
| Outer Ring Land Profile | Standard |
| Overall Length | 10 1/4" |
| Pilot Configuration | With Pilot |
| Pilot Diameter | 7 3/8" |
| Platform | RPB Series |
| Replaceable Insert | Yes |
| Retainer Material | Steel |
| Retainer Type | Metal |
| Seal Flinger | Yes |
| Series | RFPA Series |
| Shaft Size | 3 7/16" |
| Width | 11" |
| no. links/ ft. | 0 |
Product Details
Shipping Information
| Height | 27.94 |
|---|---|
| Length | 27.94 |
| Width | 16.84 |
| Country Of Origin | US |
|---|---|
| Weight | 19.170000 |
Related Products
| Style | Model | Bore Dia. | Housing Material | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|
| A | RFPA 215 | 2 15/16" | Cast Iron | 1,511.52 | |
| A | RFPA 212 | 2 3/4" | Cast Iron | 3,066.88 | |
| B | RFPA 106 | - | Cast Iron | 2,346.19 | |
| C | RFPA 203 | 2 3/16" | Cast Iron | 880.42 | |
| A | RFPA 103 | 1 3/16" | Cast Iron | 970.23 | |
| D | RFPA 315 | 3 15/16" | Cast Iron | 3,505.65 | |
| E | RFPA 107 | 1 7/16" | Cast Iron | 827.43 |
