SEALMASTER

See our 858 reviews on trustpilot

SEALMASTER MSF-39 HT 712222 Flange Ball Bearing, 4 Bolt, Black Oxided, Setscrew Lock, High Temperature, 2.438 Inch

Item: BF6RTY
Model: MSF-39 HT
In Stock

Get it by Thursday, Apr 16

£1050.88/unit (Inc. VAT)
Trade Prices Available
Request Quote

Payment

Delivery

Specifications

Ability To Relubricate Yes
Bearing Insert Finish Black Oxide
Bearing Insert Material Steel
Bearing Insert Material Grade 52100
Bearing Insert Type Medium Duty
Bearing Type Medium Duty
Bolt Size 5/8"
Bolt Spacing 5 7/8"
Bore Dia. 2 7/16"
Bore Shape Straight
Cage Type Land Riding Retainer
Dynamic Load Capacity 13971 lbs.
End Cap No
Fixed Vs. Expansion Fixed
Foot Height 0.69"
Grade Grade 52100
Grease Fitting Thread Size 1/8"
Grease Fitting Thread Type NPT
Height 3 1/2"
Housing Backside Inner Diameter 5.13"
Housing Coating Powder Coated
Housing Color Black
Housing Construction One Piece
Housing Material Cast Iron
Housing Style Flange Block
Housing Type Flange, Four Bolt
Htc 8483.20.4040
Inner Race Heat Treat Method Zone Hardened
Inner Ring Outside Dia. 3.433"
Inner Ring Outside Diameter 3.433"
Inner-race Heat-treat Method Zone Hardened
Insert 3-27 HT
Length 8.13"
Length Through Bore 2.748"
Lubricant Lithium Complex Grease With Synthetic Oil
Lubrication Type Lithium Complex Grease With Synthetic Oil
Max. Operating Temperature 400°F
Max. Speed 1100 RPM
Misalignment Type Static Only
Options High Temperature
Outer Ring Land Profile Standard
Overall Height 3"
Overall Length 7.38"
Overall Width 7.38"
Pilot Configuration No Pilot
Radial Clearance Increased
Rolling Element Ball Bearing
Seal Type High Temp Labyrinth
Shaft Locking Type Set Screw
Size Code 2-211
Static Load Rating 10063 lbs.
Width 7.94"

Product Details

Shipping Information

Height 20.17
Length 20.65
Width 8.89
Country Of Origin US
Weight 7.380000
