| Body Height | 2.24" |
|---|---|
| Durometer | 55A |
| Height | 2 6/25" |
| Isolator Body Material | Natural Rubber |
| Material | Natural Rubber |
| Max Load Downward Compression | 2035 lbf. |
| Max Load Sideways Shear | 3639 lbf. |
| Max. Load Downward Compression | 2035 lbf. |
| Max. Load Sideways Shear | 3639 lbf. |
| Max. Operating Temp. | 176°F |
| Mounting | Compressor, Motor, Pump |
| Operating Temperature - Maximum | 176°F |
| Operating Temperature - Minimum | -40°F |
|---|---|
| Overall Dia. | 3.11" |
| Overall Diameter | 3.11" |
| Resistant To | Abrasion, Wear |
| Shape | Cylindrical |
| Stud Length | 1.26" |
| Stud Or Tap Material | Steel |
| Tap Depth | 0.47" |
| Thread Material | Zinc Plated Steel |
| Thread Size | 1/2"-13 |
| Type | One Tapped Hole, One Threaded Stud |
| Vibration Isolator Style | Male x Female |
| Height | 2.54 |
|---|---|
| Length | 2.54 |
| Width | 2.54 |
|---|---|
| Weight | 0.518800 |
| Style | Model | Shape | Thread Size | Max. Load Downward Compression | Max. Load Sideways Shear | Overall Dia. | Stud Length | Tap Depth | Mounting | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 451.1-62-32-1/2-55 | Cylindrical | 1/2"-13 | 762 lbf. | 2547 lbf. | 2 11/25" | 0.87" | - | Compressor, Motor, Pump | 54.15 | |
| A | 451.1-79-57-1/2-55 | Cylindrical | 1/2"-13 | 1574 lbf. | 2815 lbf. | 3.11" | 1.26" | - | Compressor, Motor, Pump | 127.69 | |
| A | 451.1-19-19-1/4-55 | Cylindrical | 1/4"-20 | 58 lbf. | 289 lbf. | 3/4" | 0.51" | - | Compressor, Motor, Pump | 15.01 | |
| A | 451.1-25-25-1/4-55 | Cylindrical | 1/4"-20 | 168 lbf. | 667 lbf. | 0.98" | 0.51" | - | Compressor, Motor, Pump | 16.59 | |
| A | 451.1-25-13-1/4-55 | Cylindrical | 1/4"-20 | 154 lbf. | 1030 lbf. | 0.98" | 0.51" | - | Compressor, Motor, Pump | 15.52 | |
| A | 451.1-25-19-1/4-55 | Cylindrical | 1/4"-20 | 183 lbf. | 1223 lbf. | 0.98" | 0.63" | - | Compressor, Motor, Pump | 18.10 | |
| A | 451.1-32-19-1/4-55 | Cylindrical | 1/4"-20 | 283 lbf. | 1892 lbf. | 1.26" | 0.51" | - | Compressor, Motor, Pump | 24.90 |
