| Body Height | 0.81" |
|---|---|
| Height | 0.81" |
| Isolator Body Material | Buna-N |
| Isolator Material | NBR |
| Max Load Downward Compression | 96.67 lbf. |
| Max Load Sideways Shear | 468 lbf. |
| Max. Load Downward Compression | 96.67 lbf. |
| Max. Operating Temp. | 176°F |
| Maximum Load Sideways Shear | 468 lbf. |
| Mounting | Conveyor |
| Operating Temperature - Maximum | 176°F |
| Overall Dia. | 0.98" |
|---|---|
| Overall Diameter | 0.98" |
| Resistant To | Abrasion, Alkaline, Grease, Oil, Petrol, Wear |
| Shape | Conical |
| Stud Or Tap Material | Steel |
| Style | One Tapped Hole |
| Tap Depth | 15/64" |
| Taper Diameter | 0.65" |
| Thread Material | Zinc Plated Steel |
| Thread Size | 1/4"-20 |
| Vibration Isolator Style | Female x Non Threaded |
| Weight | 0.014800 |
|---|
| Style | Model | Isolator Material | Thread Size | Height | Stud Or Tap Material | Style | Max. Load Downward Compression | Shape | Maximum Load Sideways Shear | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 453.1-19-25-1/4-55 | Natural Rubber | 1/4"-20 | 0.98" | Stainless Steel | One Threaded Stud | 22 lbf. | Conical | 90.96 lbf. | 11.35 | |
| B | 254-25-1/4X20-25.4-55 | Natural Rubber | 1/4"-20 | 0.81" | Stainless Steel | One Threaded Stud | 96.67 lbf. | Conical | 468 lbf. | 10.13 | |
| B | 254-25-1/4X20-12.7-55 | Natural Rubber | 1/4"-20 | 0.81" | - | One Threaded Stud | 96.67 lbf. | Conical | 468 lbf. | 11.40 | |
| A | 453.1-45-51-3/8-55 | Natural Rubber | 3/8"-16 | 2.01" | Stainless Steel | One Threaded Stud | 168 lbf. | Conical | 284 lbf. | 74.89 | |
| B | 254-50-3/8X16-31.8-55 | Natural Rubber | 3/8"-16 | 1.69" | Stainless Steel | One Threaded Stud | 364 lbf. | Conical | 885 lbf. | 41.22 | |
| A | 453.1-51-57-3/8-55 | Natural Rubber | 3/8"-16 | 2 6/25" | Stainless Steel | One Threaded Stud | 191 lbf. | Conical | 285 lbf. | 96.60 | |
| A | 453.1-32-38-5/16-55 | Natural Rubber | 5/16"-18 | 1 1/2" | Stainless Steel | One Threaded Stud | 45 lbf. | Conical | 155 lbf. | 25.77 |
