| Item | Reducer |
| Assembly | HMQ-H |
| Bore Code | 12 |
| Center Distance | 1.77" |
| Frame | 56C |
| Gear Type | Worm |
| Gearbox Type | Worm |
| Housing Material | Aluminum |
| Input Bore (c Face) | 5/8" |
| Input Bore Size | 5/8" |
| Input Dia. | 5/8" |
| Input Keyway Size | 3/16" x 1" |
| Input Keyway Size (c Face) | 3/16" x 3/32" |
| Input Rpm | 1750 RPM |
| Input Style | C Face Quill |
| Material | Aluminum |
| Max. Input Hp | 0.981 hp |
| Model | W5180072.00 |
| Mounting Type | Shaft Mount |
| No. Of Gear Reductions | 1 |
| Output Diameter | 3/4" |
| Output Hp | 31/40 hp |
| Output Key Size | 3/16" x 1" |
| Output Rpm | 175 RPM |
| Output Shaft | Hollow Bore |
| Output Shaft Assembly Code | H |
| Output Shaft Orientation | H |
| Output Shaft Type | Hollow Shaft |
| Output Style | H |
| Output Torque | 279 lbs.-in. |
| Product Line | Bravo Series - Compact Aluminum Worm Speed Reducers |
| Reducer | Worm - Right Angle |
| Reduction Type | Single |
| Series | Bravo Series |
| Series Style | HMQ51-H |
| Service Factor | 1 |
| Shaft Seal Material | Nitrile |
| Ships Factory Direct | No |
| Weight | 6 lbs. |
| Ship weight (kg) | 2.7 |
| Ship height (cm) | 26.67 |
| Ship length (cm) | 27.15 |
| Ship width (cm) | 23.01 |
| Model | Price | |
|---|---|---|
| W5180078.00 | £495.98 | |
| W5180074.00 | £452.09 | |
| W5180071.00 | £452.09 | |
| W5180073.00 | £428.52 | |
| W5180075.00 | £452.09 | |
| W5180139.MB | £500.63 | RFQ
|
| W5180076.00 | £495.98 |
