EATON HMCPE100R3CBP08 Motor Circuit Protector, 100A, 3-Pole, 600 V, 250 Vdc, Frame J-K, 300-1000A, Non-Aluminum
Item: BH3FPP
Model: HMCPE100R3CBP08
In Stock
Get it by Wednesday, Apr 15
£3562.85/unit
Trade Prices Available
Request Quote
Payment
Delivery
Specifications
| Amperage Rating | 100A |
|---|---|
| Features | Bulk Pack 8 |
| Frame Size | Frame J-K |
| Height | 6" |
| Length | 13 1/4" |
| Magnetic Trip Range | 300-1000A |
| Mfr. Series | Series G |
| Notes | Motor FLA Ranges Typical. The Corresponding Trip Setting Is at 13X The Minimum FLA Value Shown. For DC Applications, Trip Levels Are 40% Higher Than Values Shown. Includes Line And Load Steel Body Termianls For Cu Only Wire, 14 - 1/0. |
|---|---|
| Number Of Poles | 3 |
| Terminals | Non Aluminum |
| Type | Motor Circuit Protector |
| Voltage | 600V, 250V DC |
| Warranty | Eaton Selling Policy 25-000, One (1) Year From The Date Of Installation Of The Product Or Eighteen (18) Months From The Date Of Shipment Of The Product, Whichever Occurs First. |
| Width | 0.001" |
Product Details
Motor Circuit Protector
Shipping Information
| height | 15.24 |
|---|---|
| length | 33.66 |
| country of origin | US |
|---|---|
| weight | 0.000400 |
Related Products
| Style | Model | Frame Size | Voltage | High Amp Trip Setting | Low Amp Trip Setting | Number Of Poles | Circuit Breaker Type | Ac Voltage Rating | Phase | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | HMCPE003A0C | Frame J-K | 480V | - | - | 3 | - | - | - | 1,134.35 | |
| B | HMCPE007C0C | Frame J-K | 480V | - | - | 3 | - | - | - | 1,134.35 | |
| C | HMCPE015E0C | - | 480V | 13A | 3.4A | 3 | Standard | 600V AC | Three | 1,134.35 | |
| C | HMCPE030H1C | - | 480V | 26A | 3.9A | 3 | Standard | 600V AC | Three | 1,134.35 | |
| A | HMCPE050K2C | - | 480V | 43.5A | 11.5A | 3 | Standard | 600V AC | Three | 1,134.35 | |
| A | HMCPE070M2C | - | 480V | 60.9A | 16.1A | 3 | Standard | 600V AC | Three | 1,435.71 | |
| C | HMCPE100R3C | - | 480V | 84.5A | 23A | 3 | Standard | 600V AC | Three | 1,435.71 |
