| Amperage Rating | 4.3A |
|---|---|
| Application | Industrial General Purpose Drive |
| Brake Chopper | Brake Chopper |
| Brake Chopper Included | Yes |
| Color | White |
| Communication | EtherNet, RS-485, BACnet MS/TP, Modbus TCP And RTU Communication |
| Control Method | Active Energy Control |
| Control Type | Keypad |
| Depth | 17.3" |
| Display Type | LCD |
| Displays | LCD Keypad |
| Dynamic Braking | Yes |
| Enclosure | Open |
| Enclosure Rating | NEMA 1 |
| Ethernet Port Included | Yes |
| Form Factor | 0.01 Hz Resolution |
| Frame Size | FR1 |
| Frequency Rating | 50-60 Hz |
| Height | 12.7" |
| Hp | 2 hp |
| Input Frequency | 50/60 Hz |
| Input Phase | 3 |
| Input Phase Ac | 3 |
| Input Type | Analog, Digital |
| Input Voltage | 480V AC |
| Input Voltage Range | 380-500V AC |
| Ip Rating | IP21 |
| Keypad | Included |
| Maximum Output Current | 4.3A |
| Maximum Output Power | 2 hp |
|---|---|
| Mfr. Series | General Purpose |
| Nema Enclosure Rating | NEMA 1 |
| Number Of Inputs | 8 Digital Inputs, 2 Analog Input |
| Number Of Outputs | (1) Digital Output, (2) Analog Output |
| Number Of Slots | 2 |
| Output Frequency Range | 0-400 Hz |
| Output Phase | 3 |
| Output Type | Analog, Digital |
| Output Voltage | 480V AC |
| Output Voltage Range | 380-500V AC |
| Overall Depth | 17 3/8" |
| Overall Height | 12 5/8" |
| Overall Width | 9" |
| Power Consumption | 1.5 kW |
| Protection | Incoming Surge, Input Phase Loss, Output Phase Loss, Overcurrent, Overheating, Overload, Overvoltage, Stall, Under Voltage |
| Series | POWER XL DRIVES Series |
| Software | Active Energy Control, Quick Start Wizard |
| Start/stop Control | Programmable |
| Starting Torque | 1.5 |
| Style | Industrial High Performance |
| Torque Application | Constant Torque, Variable Torque |
| Torque Rating | CT |
| Warranty | Eaton Selling Policy 25-000 Generally Applies With Some Exceptions.Drive Products Come With A Standard 24 Months From Date Of Shipment And 36 Months With Eaton Certified Start Up All Inclusive Coverage Parts Labor And Travel. |
| Width | 9" |
| With Bypass/no Bypass | No Bypass |
| With Line Contactor/no Line Contactor | No Line Contactor |
| standard | ROHS, GOST-R, C-TICK, CE, CUL LISTED, UL LISTED, UL 508C, EN ISO 13849-1, IEC 61508, EN 62061 |
| Height | 32.26 |
|---|---|
| Length | 43.94 |
| Width | 22.86 |
| Country Of Origin | US |
|---|---|
| Weight | 7.200000 |
| Style | Model | Input Voltage | Output Voltage | Height | Depth | Overall Width | Overall Depth | Overall Height | Hp | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | DG1-32012FB-C21C | 240V AC | 240V AC | 14 1/2" | 21" | 10 1/2" | 21" | 14 1/2" | 5 hp | 1,774.21 | |
| B | DG1-32011FB-C21C | 240V AC | 240V AC | 13" | 17 1/2" | 9" | 17 1/2" | 13" | 3 hp | 1,510.71 | |
| A | DG1-32017FB-C21C | 240V AC | 240V AC | 15" | 21" | 10 1/2" | 21" | 14 1/2" | 5 hp | 1,870.24 | |
| A | DG1-32025FB-C21C | 240V AC | 240V AC | 16" | 28" | 15" | 28" | 16" | 7 1/2 hp | 2,631.42 | |
| C | DG1-32031FB-C21C | 240V AC | 240V AC | 16" | 27" | 12" | 27" | 16" | 10 hp | 2,422.69 | |
| C | DG1-32048FB-C21C | 240V AC | 240V AC | 16" | 27" | 11 1/2" | 27" | 16" | 15 hp | 3,014.87 | |
| D | DG1-32061FN-C21C | 240V AC | 240V AC | 17" | 28" | 15" | 28" | 17" | 20 hp | 4,639.27 |
