BEST F179 3X3 DOOR HINGE 3 STL Template Hinge Removable Bright Brass

Item: AE3WFZ
Model: F179 3X3 DOOR HINGE 3 STL
20 In Stock

Ships within 2 days via

£14.56
5.00% off
£13.84/unit (Inc. VAT)
Trade Prices Available
Request Quote

Payment

Specifications

Bearing Type Plain
Color Brass
Corner Type Square
Corners Square
Door Leaf Height 3"
Door Leaf Length 3"
Door Leaf Thickness 0.123"
Door Leaf Width 1 1/4"
Door Thickness 1 3/8"
Features For Use On Internal Or External Doors Without Door Closers, Hinges Can Be Furnished With Hospital Tips (HT), Template Screw Hole Location
Finish Bright Brass, Clear Coated
Frame Leaf Thickness 0.123"
Frame Leaf Width 1 1/4"
Hardware Included
Height 3"
Holes Per Leaf 3.0
Includes Hardware Hardware Included
Leaf Thickness 0.092"
Load Capacity 75 lbs.
Material Steel
Mounting Full Mortise
Mounting Style Full Mortise
Number Of Holes Per Leaf 3
Overall Height 3"
Overall Width 3"
Pin Dia. 0.234"
Pin Diameter 1/4"
Pin Material Steel
Pin Type Removable
Range Of Motion 180°
Range Of Motion - Maximum 270°
Removable Pin Yes
Standard Logo ansi.jpg,bhma.jpg
Standards Ansi, Bhma
Stanley Class Number F179
Stanley Edp Number 53256
Width 3"

Product Details

Shipping Information

Height 2.54
Length 11.94
Width 2.54
HS Code 8302106030
Country Of Origin CN
Weight 0.099000
